Automatic Sliding Doors
Erichsen Automatic Door


Erichsen Automatic Door


Erichsen Automatic Door


With uniform operation, long service life and minimal maintenance, the EAD24 operator has proved is reliability and longevity in Office buildings, hospitals, restaurants, hotels, etc. This system is manufactured in accordance with the relevant standards, is fully compliant with the German standards and complies with DIN 18650.

Standard functions

  • Detection of obstacles in opening and closing direction with safety stop function and subsequent reboot in the gentle.
  • Self-learning control system with integrated safety monitoring.
  • Adjustable opening and closing speed.
  • Selector to select of the following modes: automatic operation, winter operation (reduced opening width), full opening, one-way traffic, locked.
  • Combined motion / presence detectors with higher accuracy and less installation effort and improved door profiles.




  • Electromagnetic lock set
  • Outdoor key switch for night access Connection to the PC module
  • Connection to the mobile phone via Bluetooth
  • Manual readout mechanism
  • Connectivity to the LON network
  • High-performance battery, which allows hundreds of opening and closing cycles


Key Switch

Digital Key Switch (option)
